UTECH Electronics Technology Co., Ltd.
-
Case size: HC-49SMD / QRSD
Frequency: 12.800000 MHz
Mode: fund. AT
Load Capacitance: 15 pF
Tolerance at +25 °C: ±10 ppm
Tolerance over Temp.: ±20 ppm
Aging: ±6 ppm max. first 5 year
ESR max.: 40 Ohm
Operating Temp.: -40°C/+85°C
-
Package Unit: 1000pcs/reel

SUZHOU UTECH TECHNOLOGY CO.,LTD
QRSD
TR1000

'-
UTECH Electronics Technology Co., Ltd.
-
Case size: HC-49SMD / QRSD
Frequency: 3.686400 MHz
Mode: fund. AT
Load Capacitance: 18 pF
Tolerance at +25 °C: ±30 ppm
Tolerance over Temp.: ±30 ppm
Aging: ±3 ppm max. 1 year
ESR max.: 120 Ohm
Operating Temp.: -40°C/+85°C
RoHS : 2011/65/EU (RoHS 2) compliant
-
Package Unit: 1000pcs/reel

Bauform: SMD3225-M4
Frequency: 27,000000 MHz
Mode: fund.
Load Capacitance: 10 pF
Tolerance at +25 °C: ±10 ppm
Tolerance over Temp.: ±50 ppm
ESR max.: 60 Ohm
Operating Temp.: -40 / +85 °C

Bauform: SMD3225-M4
Frequency: 27,000000 MHz
Mode: fund.
Load Capacitance: 12 pF
Tolerance at +25 °C: ±10 ppm
Tolerance over Temp.: ±10 ppm
ESR max.: 60 Ohm
Operating Temp.: -20 / +70 °C

Bauform: SMD3225-M4
Frequency: 27,000000 MHz
Mode: fund.
Load Capacitance: 12 pF
Tolerance at +25 °C: ±10 ppm
Tolerance over Temp.: ±50 ppm
ESR max.: 60 Ohm
Operating Temp.: -20 / +70 °C

Bauform: SMD3225-M4
Frequency: 27,000000 MHz
Mode: fund.
Load Capacitance: 12 pF
Tolerance at +25 °C: ±10 ppm
Tolerance over Temp.: ±20 ppm
ESR max.: 60 Ohm
Operating Temp.: -40 / +85 °C

'-
Epson P/N: Q3614CA00102700
Description: VG-4231CA 32.000000MHZ GRC-F
-
MOQ: 1000
Packing Unit 1000
-
Frequency: 32000
Actual Size (mm): 7.00X5.00X1.40
Voltage Supply: 3.3V
Output: CMOS

RIVER Electronics (S) Pte Ltd

Typ: SMD-Oscillator HCMOS
Case size: SMD2520-M4 | FCXO-05D
Dimension: 2.5 × 2.0 × 0.9 mm
Frequency: 32.768000 kHz
Power Supply Voltage: +3.3V ±10%
Frequency Stability: ±20 ppm
Operating Temp.: -40°C/+85°C

Package Unite: 3000pcs/reel

Bauform: SMD3225-M4
Frequency: 32,000000 MHz
Mode: fund.
Load Capacitance: 12 pF
Tolerance at +25 °C: ±10 ppm
Tolerance over Temp.: ±10 ppm
ESR max.: 60 Ohm
Operating Temp.: -20 / +70 °C

'-
UTECH Electronics Technology Co., Ltd.
Package: SMD3225-M4
Frequency: 40.000000 MHz
Mode: fund. AT
Load Capacitance: 20 pF
Tolerance at +25 °C: ±10 ppm
Tolerance over Temp.:±15 ppm
Aging: ±2 ppm max. 1 year
ESR max.: 25 Ohm
Operating Temp.: 0°C/+85°C

Bauform: SMD3225-M4
Frequency: 12,000000 MHz
Mode: fund.
Load Capacitance: 12 pF
Tolerance at +25 °C: ±10 ppm
Tolerance over Temp.: ±30 ppm
ESR max.: 60 Ohm
Operating Temp.: -20 / +70 °C

Utech Electronics Technology Co., Ltd.

Frequency: 26.000000 MHz
Oscillation Mode: Fundamental
Supply Voltage (VCC): 1.8V to 3.3V
Input Current: 1.5 mA max
Output Level Clipped Sine(Vp-p): 0.8V min
Harmonics: -5 dBc max
Frequency Tolerance After Reflow (at +25°C): ±2 ppm max
Frequency Stability Vs Temperature Range: ±2 ppm max
Operating Temperature Range: -40~+85°C
Temperature slope @-20~+70°C: ±0.1 ppm / °C
Temperature slope @-40~+85°C: ±0.3 ppm / °C
Storage Temperature Range: -40~+85°C
Frequency Stability Vs Supply Voltage (±5%): ±0.2 ppm
Frequency Stability Vs Load (±10%): ±0.2 ppm
Output Waveform: Clipped Sine wave
Output Load: 10 KΩ // 10 pF
Start-up Time Vs frequency: ≤ 2.0 ms / within ±1 ppm
Aging : ±1 ppm max first year

Package Unit: 3000pcs/reel

'-
Manufacturer: Utech Electronics Technology Co., Ltd.
-
Type: TCXO-SMD3225-M4 - CSW Output (Clipped Sine Wave)
-
Frequency: 14.745600 MHz
Supply Voltage (VDD): +3.3 VDC ±5%
Input Current: 1.5 mA max.
-
Frequency Stability vs Temperature Range: ±2.5 ppm max. over -30°C ~+85°C
Frequency Stability Vs Supply Voltage (±5%): ±0.2 ppm max,
Frequency Stability Vs Load (±10%). ±0.2 ppm max.
Aging: ±1.0ppm max./year
-
phase noise max.:
-80 dBc/Hz at 10 Hz
-110 dBc/Hz at 100 Hz
-130 dBc/Hz at 1 kHz
-145 dBc/Hz at 10 kHz
-150 dBc/Hz at 100 kHz
-150 dBc/Hz at 1 MHz
-
Output Logic / Output Load: Clipped Sine Wave / 10 kOhm, 10 pF
Operating Temperature: -30°C to +85°C
Storage Temperature: -40°C to +85°C
Start-up Time: ≤ 2 ms
-
Package Unit: 1000pcs/reel

Bauform: SMD5032-M4
Frequency: 8,000000 MHz
Mode: fund.
Load Capacitance: 16 pF
Tolerance at +25 °C: ±10 ppm
Tolerance over Temp.: ±100 ppm
ESR max.: 40 Ohm
Operating Temp.: -40 / +85 °C

Bauform: SMD5032-M4
Frequency: 9,216000 MHz
Mode: fund.
Load Capacitance: 16 pF
Tolerance at +25 °C: ±10 ppm
Tolerance over Temp.: ±30 ppm
ESR max.: 80 Ohm
Operating Temp.: -20 / +70 °C

'-
Manufacturer: Utech Electronics Technology Co., Ltd.
Series: Oscillator SMD5032-M4
Type: TCXO-SMD5032-M4
Frequency: 20.000000 MHz
Supply Voltage (VDD): +3.3 VDC ±10%
Input Current: 6 mA max.
Frequency Tolerance: ±2.5 ppm
Output Logic / Output Load: CMOS / 15 pF
Operating Temperature: -30°C to +85°C
Storage Temperature: -55°C to +125°C
Phase Noise at 12,80 MHz: -125dBc/Hz at 100 Hz, -145dBc/Hz at 1 kHz, -150dBc/Hz at 10 kHz
Start-up Time: ≤ 2 ms
Package Unit: 1000pcs/reel

Manufacturer: Utech Electronics Technology Co., Ltd.

Series: Oscillator SMD3225-M4 / QZS3
Type: VCTCXO-SMD3225-M4
Frequency: 19.200000 MHz
Supply Voltage (VDD): +3.3 VDC ±5%
Input Current: 2.0 mA max.
Frequency Tolerance: ±1.5 ppm

Output Logic | Output Load: Clipped Sine Wave | 10kΩ / 10pF
Operating Temperature: -30°C to +85°C
Storage Temperature: -40°C to +85°C

Absolute Pulling Range (APR): ±20 ppm min., ±30ppm max.
Control Voltage Range: 1.65V ±1.0V

Phase Noise at 12,80 MHz:
-90dBc/Hz at 10 Hz
-115dBc/Hz at 100 Hz
-128dBc/Hz at 1 kHz
-145dBc/Hz at 10 kHz
-149dBc/Hz at 100 kHz
-150dBc/Hz at 1 MHz

Start-up Time: ≤ 2 ms

Package Unit: 1000pcs/reel

Manufacturer: UTECH TECHNOLOGY CO.,LTD

Case Size: Oscillator TCXO SMD2016-M4
Series: QPS1
Type: TCXO - CSW Output (Clipped Sine Wave)
Frequency: 26.000000 MHz (fundamental)
Supply Voltage (VDD): 1.8 V ±5%
Input Current: 2.0 mA max.

Frequency Tolerance (at +25°C): ±1.0 ppm
Frequency Tolerance over Temperature: ±1.0 ppm @ -40/+85°C
Frequency Stability Vs Supply Voltage (±5%): ±0.2 ppm
Frequency Stability Vs Load (±10%). ±0.2 ppm
Aging: ±1.0 ppm/yer max.

Output Logic / Output Load: CSW - Clipped Sine Wave (min. 0.8V) / 10 KΩ // 10pF
Operating Temperature: -40°C to +85°C
Storage Temperature: -55°C to +125°C

Phase Noise
@ 1 kHz offset < -130dBC/Hz
@ 10 kHz offset <-140dBC/Hz
@ 100 kHz offset <-150dBC/Hz

Package: 3000pcs/reel

'-
Manufacturer: Utech Electronics Technology Co., Ltd.
Series: Oscillator SMD5032-M4 / QPS5
Type: VCTCXO-SMD5032-M4
Frequency: 25.000000 MHz
Supply Voltage (VDD): +2.4 ~ 5.5 VDC
Input Current: 1.5 mA max.
Frequency Tolerance: ±1.5 ppm
Supply voltage stability: ±0.2ppm, VDD ±5%
Load stability: ±0.2ppm, ZL ±10%
Ageing: ±1.0ppm max first year
Output Logic / Output Load: Clipped Sine Wave / 10kΩ// 10pF
Operating Temperature: -30°C to +75°C
Storage Temperature: -45°C to +85°C
Phase noise (typ @ 20.0MHz): -54dBc/Hz @ 1Hz -86dBc/Hz @ 10Hz -135dBc/Hz @ 1kHz -151dBc/Hz @ 100kHzStart-up Time: ≤ 2 ms
Package Unit: 1000pcs/reel

SUZHOU UTECH TECHNOLOGY CO.,LTD
QRS5
TR1000

'-
UTECH, SMD5032-M4, 8.000000 MHz, fund., 20pF, ±20ppm@+25°C, ±30ppm over Temp., ESR max.: 80 Ohm, -20/+70°C

'-
UTECH Electronics Technology Co., Ltd.
Type: THT HC-49/S (QRDS)
Frequency: 5.000000 MHz
Mode: fund. AT
Load Capacitance: 16 pF
Tolerance at +25 °C: ±30 ppm
Tolerance over Temp.: ±30 ppm
Aging: ±3ppm max. 1 year
ESR max.: 150 Ohm
Operating Temp.: -20°C/+70°C

UTECH Electronics Technology Co., Ltd.

Case Size: SMD3225-M4
Frequency: 40.000000 MHz
Mode: fund. AT-Cut
Load Capacitance: 20.0 pF
Tolerance at +25 °C: ±9 ppm
Tolerance over Temp.: ±9 ppm
ESR max.: 20 Ohm
Operating Temp.: -20°C / +70°C

Package Unit: 3000pcs/reel

Bauform: SMD3225-M4
Frequency: 48,000000 MHz
Mode: fund.
Load Capacitance: 16 pF
Tolerance at +25 °C: ±10 ppm
Tolerance over Temp.: ±50 ppm
ESR max.: 60 Ohm
Operating Temp.: -20 / +70 °C

'-
UTECH Electronics Technology Co., Ltd.
-
Case Size: SMD3225-M4
Frequency: 16.000000 MHz
Mode: fund. AT
Load Capacitance: 7 pF
Tolerance at +25 °C: ±50 ppm
Tolerance over Temp.: ±50 ppm
Aging: ±3ppm max 1 year
ESR max.: 60 Ohm
Shunt Capacitance: 5pF max.
Operating Temp.: -55°C/+125°C
-
Package Unit: 3000pcs/reel

UTECH Technology Co., Ltd.

Case size: HC-49SMD
Frequency: 4.000000 MHz
Mode: fund. AT
Load Capacitance: 20.0 pF
Tolerance at +25 °C: ±30 ppm
Tolerance over Temp.: ±30 ppm
Aging: ±3 ppm max. 1 year
ESR max.: 80 Ohm
Operating Temp.: -40°C/+85°C

Package Unit: 1000pcs/reel

'-
Manufacturer: UTECH Electronics Tech. Co., Ltd.
-
Series: QRSE
Case size: HC-49SMD3 (11.40 x 4.70 x 3.20 | 3Pin)
Frequency: 10.368000 MHz
Mode: fund. AT
Load Capacitance: 10 pF
Tolerance at +25°C: ±10 ppm
Tolerance over Temp.: ±10 ppm
Aging: ±3 ppm max. first year, ±10 ppm after 8 years
ESR max.: 50 Ohm
-
Condition of unwanted response: RN/Rr < 2.5
Shunt Capacitance: C0 = tbd
Motional Capacitance: C1 = tbd
Pulling Sensitivity: S = 17,0 ppm/pF ±20%
-
Operating Temp.: -10°C/+60°C
-
Package Unit: 1000pcs/reel

SUZHOU UTECH TECHNOLOGY CO.,LTD
TR3000

'-
UTECH Electronics Technology Co., Ltd.
-
Case Size: SMD1210-M4 (1.2 x 1.0 mm))
Frequency: 38.400000 MHz
Mode: fund. AT
Load Capacitance: 8.5 pF
Tolerance at +25°C: ±10 ppm
Tolerance over Temp. -20/+75°C: ±10 ppm
Aging: ±3ppm max 1 year
ESR max.: 60 Ohm
Operating Temp.: -40°C/+85°C
-
Package Unit: 3000pcs/reel
