O-VCTCXO-SMD2520-M4-64.000000 MHz-3.3-4085-CSW
SUZHOU UTECH TECHNOLOGY CO.,LTD
Type: Oscillator VCTCXO-SMD2520-M4
Frequency: 64.000000 MHz
Supply Voltage (VDD): +3.3 VDC ±5%
Input Current: 2.0 mA max.
Frequency Tolerance: ±1.0 ppm
... Frequency tolerance: ±1.0 ppm max. @+25°C
... Frequency Stability Vs Temperature Range: ±0.5 ppm max
... Frequency Stability Vs Supply Voltage (±5%): ±0.2 ppm max
... Frequency Stability Vs Load (±10%): ±0.2 ppm max
... Frequency aging: ±1.0 ppm/year max
Absolute Pulling Range (APR): ±20 ppm min
Control Voltage Range: 1.65V±1.0V
Output Waveform: Clipped Sine wave
Output Load: 10 KΩ // 10 pF
Start-up Time Vs frequency 2.0 ms max within ±1.0 ppm
Operating Temperature: -40°C to +85°C
Storage Temperature: -55°C to +125°C
Phase Noise
... 10Hz Offset: -70 dBc/Hz
... 100Hz Offset: -105 dBc/Hz
... 1KHz Offset: -125 dBc/Hz
... 10KHz Offset: -145 dBc/Hz
... 100KHz Offset: -155 dBc/Hz
Package Unit: 1000pcs/reel
Specifications
| 3.01 Nominal Frequency (Fo) | 64.000000 MHz |
| 3.02 Supply Voltage (VDD) | 3.3 |
| 3.03 Input Current | 2.0 mA |
| O 3.04 Frequency Stability Over All * | - |
| O 3.05 Operating Temp. Range | -40°C ~ +85°C |
| 3.07 Output Logic | - |
| 3.08 Output Load | 10 pF |
| 3.09 “1” Level | - |
| 3.10 “0” Level | Voltage (VDD): +3.3 VDC ±5% |
| O 3.11 Symmetry | - |
| O 3.12 Rise / Fall Time | - |
| O 3.13 Output Disable / Enable Delay Time | - |
| O 3.14 Start-up Time | Start-up Time Vs frequency 2.0 ms max within ±1.0 ppm |
