O-SMD2520-M4-32.768000 kHz-3.3-20-4085 | FCXO-05D
RIVER Electronics (S) Pte Ltd
Typ: SMD-Oscillator HCMOS
Case size: SMD2520-M4 | FCXO-05D
Dimension: 2.5 × 2.0 × 0.9 mm
Frequency: 32.768000 kHz
Power Supply Voltage: +3.3V ±10%
Frequency Stability: ±20 ppm
Operating Temp.: -40°C/+85°C
Package Unite: 3000pcs/reel
Specifications
| 3.01 Nominal Frequency (Fo) | 32.768000 kHz |
| 3.02 Supply Voltage (VDD) | 3.3 |
| 3.03 Input Current | - |
| O 3.04 Frequency Stability Over All * | 20 |
| O 3.05 Operating Temp. Range | -40°C ~ +85°C |
| 3.07 Output Logic | HCMOS |
| 3.08 Output Load | - |
| 3.09 “1” Level | - |
| 3.10 “0” Level | - |
| O 3.11 Symmetry | - |
| O 3.12 Rise / Fall Time | - |
| O 3.13 Output Disable / Enable Delay Time | - |
| O 3.14 Start-up Time | - |
